Number Parameter Technical specification Remarks
1 Layers 1-16
2 Material FR-4 CEM-3 CEM-1 FR-1 Special materials according to customer requirements
3 Finished board thickness 0.4-6.0MM(15-236mil)
4 Min-core thickness 0.2MM(8mil)
5 Resistance welding bridge 0.076MM(3mil)
6 Copper thickness HOZ 1OZ 2OZ 3OZ
7 Min.trace width&line space double layer 0.1MM(4mil)
8 Multi layer 0.1MM(4mil)
9 Min-hole diameter Drilling/PTH ∮0.15MM(6mil)
10 Punching ∮0.7MM(28mil)
11 Dimension tolerance Hole position ±0.05MM(±2mil)
12 (W)Width ±20% Special case±10%
13 (H)Hole diameter PTH±0.076MM(±3mil)
14 (H)Hole diameter NPTH±0.05MM(±2mil)
15 Outline dimension 0.1MM(4mil)
16 Conductors&Outline 0.20MM(8mil)
17 Warp and Twist 0.75%
18 Surface treatment HAL&Lead Free HAL
AU/NI
Immersion gold/Immersion sliver/Immersion Tin
OSP
OSP (+Immersion gold,+gold finger,no peel)
19 ET Number of tests (MAX) ET machine:12288 point;
Insulation resistance testing(MAX) 50MΩ
Conduction resistance test(MIN) ET machine:20Ω
Testing the size of PAD(MIN) 0.25MM(10mil)
Welding test plate of center distance(MIN) 0.2MM(8mil)
Testing Voltage(MAX) 500V
High Voltage test voltage(MAX) 5000V
High voltage test leakage voltage(MIN) 10uA
Testing the size of PCB 450*965MM
Testing the thickness of plating 0.4-6.0MM(15-236mil)
